Site Alarm & Data Monitoring System

Project Overview

ESP8266 fetches data from RS485-enabled devices like AMF Panel, SMPS, IPMS, DCEM, etc.
Data sent to central web server
Authorized users can access alarms and measurements online
Provides real-time monitoring and alerting

System Architecture

Site devices (AMF Panel, SMPS, energy meters)
ESP8266 collects data via RS485
Data pushed to website database
Web interface displays alarms, logs, and measurements
Accessible to technicians remotely

Simple Connection Diagram

Site Devices → ESP8266 → Web Server → Technician Dashboard

AMF Panel

Alarms

Mains Fail
Load on Mains
Load on DG
DG Fail to Start
LLOP
DG Over Load
DG Voltage Low
Site on Battery
Low DC
DG Common Fault
DG Fail to Stop
Fire & Smoke
DG Start Temp
Door Open

Measurements

Site Battery Voltage
DG Battery Voltage
Mains Three Phase Voltage with Frequency
DG Three Phase Voltage with Frequency
Three Phase and Neutral Load Current
Cabin & Shelter Temperature
All run hours EB, DG, and BB
AMF Controller Current Date & Time
Internet Connection Status

Monitoring Device & Apps Testing

Web application, Android app, and monitoring device are developed for testing and demonstration purposes only.
Prototype version – data shown here is for testing only.
Dashboard is a demo for monitoring concept validation.
Monitoring Device can send JSON data to company webserver if required.
Few devices installed at site for testing and working properly.

Login & Dashboard Pages

Login Page
Monitoring Dashboard
AMF Panel Monitoring
All Alarm Monitoring
Logs with Voltage & Run Hours

Costing Details (Device + Data Pack)

Item	Approx Cost (INR)	Notes
ESP8266 module	₹150–₹250	NodeMCU or ESP-12E
RS485 Converter	₹50–₹100	TTL to RS485
4G Modem	₹1250–₹1500	Not required if WiFi available
Power Regulator Supply	₹50–₹100	5V/12V
Data Pack (SIM)	₹100–₹200 /mo	1GB to 2GB sufficient

Key Features

Real-time data monitoring
Data refresh every 40 seconds
Alarm notifications
Historical data logs
Technician-specific dashboards
Remote accessibility via web
Cost-efficient

Benefits

Improved efficiency in monitoring
Early detection of site issues
Reduced downtime
Easy access for multiple technicians
Scalable for multiple sites

Conclusion

The Site Alarm & Data Monitoring System leverages ESP8266 and web technology to provide real-time, remote monitoring of critical site parameters. It enhances reliability, improves response time, and ensures efficient maintenance.

APK Download

You can download the monitoring app below:

Download APK

Access credentials for testing:

Username: Altius

Password: pa_1word

Please do NOT change the above password — it is required for testing purposes. If the password is changed, other will be unable to log in with same credentials for testing.

Disclaimer

This web application and APK are developed for testing and demonstration purposes only. Data shown is for testing only.
